ODWAC-P Drop Cable Clamp

ODWAC-P Drop Cable Clamp


ODWAC series are tension clamps for FTTH drop cable.


The fiber drop wire clamp ODWAC is composed of a body, a wedge and a shim. A solid wire bail is crimped to the wedge. All parts are made out of stainless steel.


As a fiber optic products supplier, TUOLIMA offer this tension clamp with appropriate dead-end anchor FTTH ODWAC clamp, S-type, ACC and other FTTH clamps. All the assemblies passed the tensile tests, operation experience with temperatures ranging from -60 °C up to +60 °C test, temperature-cycling test.


tension wire clamp
tension wire clamp
tension wire clamp
tension wire clamp
tension wire clamp
tension wire clamp
GET A QUOTE
Watch the Video

Details of ODWAC-P Fiber Optic Drop Cable Clamp

  • Fiber optic cable clamps diameter range: 3-7mm;

  • Good corrosion resistant, durable and economical;

  • Made of Strengthened Nylon

  • Use with HC, YK, ODWAC-P and hoop

  • Consists of three parts: a shell, a shim and a wedge equipped with a bail wire.


Specification of ODWAC-P Drop Cable Clamp

Code

Length

Outer Material

Thickness of outer sheath

Tensile Strength

ODWAC-P

220mm

Strengthened Nylon

2.85mm

600N

Cable Diameter

Internal Material

Insert Material

Thickness of insert

Weight

3-7mm

Nylon

Nylon

2.6mm

38g



Packing and Comments of ODWAC-P Drop Cable Clamp

Package contents

ODWAC-P customized package such as 10pcs/box

Package dimensions(W*H*D)

48*34*33cm

Package material

Standard carton for sea shipping or air express

Weight

17kgs
